Item No :
SMF104ZZSize (d*D*B) :
4x10x4x11.6mmLead Time :
3-5 daysWeight :
0.0015KGShipping Port :
Guangzhou, Ningbo, ShanghaiMOQ :
100 pcs
| Item No. | SMF104ZZ |
| Branding | famous brand/RMO/Neutral/OEM |
| Sealing | OPEN, ZZ , 2RS |
| Material | carbon steel, hybrid ceramic, full ceramic,GCR15,stainless steel (420 440C 304 316) |
| Lead Time | 3-5 days |
| Precision | p0 p6 p5 p4 |
| Clearance | C2 C0 C3 C4 |
| Vibration | Z1V1, Z2V2, Z3V3 |
| Cage material | Steel, nylon, copper |
| Shipping Port | GUANGZHOU, NINGBO, SHANGHAI |
| Payment | 100% T/T, or 30% T/T In Advance ,70% T/T After Finished Production |
Precision grade: Generally, it is P0 precision grade, which is the ordinary precision grade of the bearing and can meet the needs of most conventional applications.
Limiting rotational speed: The limiting rotational speed for grease lubrication is approximately 8500 r/min, and for oil lubrication it is approximately 8600 r/min. Specific values may vary depending on different manufacturers.
| Bearings No. | ID(d*D*H)mm | Weight (KG) | Bearings No. | ID(d*D*H)mm | Weight (KG) |
| F682ZZ | 2*5*2.3 | 0.001 | MF115ZZ | 5*11*4 | 0.001 |
| F683ZZ | 3*7*3 | 0.001 | MF106ZZ | 6*10*3 | 0.001 |
| F684ZZ | 4*8*3 | 0.001 | MF126ZZ | 6*12*4 | 0.002 |
| F685ZZ | 5*11*5 | 0.002 | MF117ZZ | 7*11*3 | 0.002 |
| F686ZZ | 6*13*5 | 0.003 | MF137ZZ | 7*13*4 | 0.003 |
| F687ZZ | 7*14*5 | 0.0035 | MF128ZZ | 8*12*3.5 | 0.003 |
| F688ZZ | 8*16*5 | 0.0045 | MF148ZZ | 8*14*4 | 0.009 |
| F689ZZ | 9*17*5 | 0.005 | F626ZZ | 6*19*6 | 0.009 |
| F692ZZ | 2*6*3 | 0.001 | MF84ZZ | 4*8*3 | 0.001 |
| F693ZZ | 3*8*4 | 0.002 | FR6ZZ | 9.525*22.225*7.142 | 0.006 |
| F694ZZ | 4*11*4 | 0.003 | F605ZZ | 5*14*5 | 0.004 |
| F695ZZ | 5*13*4 | 0.003 | MF74ZZ | 4*7*2.5 | 0.001 |
| F696ZZ | 6*15*5 | 0.004 | F608ZZ | 8*22*5 | 0.024 |
| F697ZZ | 7*17*5 | 0.006 | F606ZZ | 6*17*6 | 0.007 |
| F698ZZ | 8*19*6 | 0.008 | F625ZZ | 5*16*5 | 0.005 |
| F699ZZ | 9*20*6 | 0.002 | F624ZZ | 4*13*5 | 0.002 |
| MF52ZZ | 2*5*2.5 | 0.0005 | F623ZZ | 3*10*4 | 0.023 |
| MF72ZZ | 2*7*2.5 | 0.0005 | FR8ZZ | 12.7*28.575*7.938 | 0.025 |
| MF82ZZ | 2*8*2.5 | 0.001 | F607 | 7*19*6 | 0.01 |
| MF63ZZ | 3*6*2.5 | 0.001 | FR168 | 6.35*9.52*3.18 | 0.005 |
| MF104ZZ | 4*10*4 | 0.001 | SFRW168ZZ | 3.175*9.525*2.778 | 0.007 |
| MF85ZZ | 5*8*2.5 | 0.001 | F6801 | 12*21*5 | 0.006 |
| MF95ZZ | 5*9*3 | 0.002 | F6202ZZ | 15*35*11 | 0.05 |
| MF105ZZ | 5*10*4 | 0.0009 | F6800ZZ | 10*19*5 | 0.007 |
bearing for Vacuum Cleaner
bearing for monitoring PTZ
bearing for Reduced-fat rope
| 1. Keep clean | 2. Use with caution | 3. appropriate tool | 4. Hot-loading | 5. Be careful of rust |
| Dust will have a bad effect on the bearing, so keep the surrounding clean. | Strong impact during use can easily cause scratches and indentations. | Avoid replacing existing tools, and use appropriate tools. | Bearings are precision parts, so hot installation is recommended. | Sweat on your hands during operation will cause rust, so it is best to wear gloves. |
 |
 |
 |
 |
 |
 |
 |
 |
 |
608ZZ is widely used in various types of miniature transmission systems.
Details
MR126ZZ bearings are made of chrome steel with high precision and low noise. We have large stock and can provide free samples for testing.
Details
R168ZZ bearing is made of chrome steel. Excellent performance and low noise level. We have it in stock and can provide free sample for testing.
Details
It's composed of an inner ring, an outer ring, steel balls and a cage.
Details
Similar to standard single-row deep groove ball bearings, it is composed of components such as inner ring, outer ring, steel balls and cage.
Details
This nylon cage is suitable for 51105 thrust ball bearings and is made of nylon PA66 material.
Details
The 682ZZ bearing is a type of miniature deep groove ball bearing, which is a typical small-sized rotating component used in the industrial sector.
Details
The 603 bearing belongs to the small-sized series of deep groove ball bearings. Its core features include a simple structure, high rotational speed and strong versatility.
Details
The 604ZZ P6 grade bearing that is widely used in the field of precision instruments.
Details
The 625ZZ P6 grade bearings are widely applicable to micro-motors, small household appliances and other equipment that have requirements for space and precision,
Details
The 626 2RS bearing is suitable for various light-load and high-speed applications, and is commonly found in small motors, precision instruments and other equipment.
Details
